Ball Nose Solid Carbide Endmill
Description:Solid Carbide End mills for General Use, 4 Flutes, Flattened, Metric
- Material:100% virgin material
- Brand: Nice Carbide
- Coating: AlTiN-based S3p Balzers
- Application: HRC70,for cast iron, steel and stainless steel
- OEM & ODM: OEM is welcome, colorful sticker and laser marking is free
Description
Produce all kinds of solid carbide end mills including general series, special series and customized solutions.
1. Use ultra-fine grained original raw carbide materials.
2. High performance AlTiN-based Balzers coating.
3. With high temperature resistance and high wear resistance.
4. Suitable for processing cast iron, steel and stainless steel.
Specification
| CED | Radius | CEL | OAL | Shank Dia | Teeth |
| 1 | 0.5 | 2 | 50 | 4 | 2 |
| 1.5 | 0.75 | 3 | 50 | 4 | 2 |
| 2 | 1 | 4 | 50 | 4 | 2 |
| 2.5 | 1.25 | 5 | 50 | 4 | 2 |
| 3 | 1.5 | 6 | 50 | 4 | 2 |
| 4 | 2 | 8 | 50 | 4 | 2 |
| 1 | 0.5 | 2 | 50 | 6 | 2 |
| 2 | 1 | 4 | 50 | 6 | 2 |
| 3 | 1.5 | 6 | 50 | 6 | 2 |
| 4 | 2 | 8 | 50 | 6 | 2 |
| 5 | 2.5 | 10 | 50 | 6 | 2 |
| 6 | 3 | 12 | 50 | 6 | 2 |
| 7 | 3.5 | 14 | 60 | 8 | 2 |
| 8 | 4 | 16 | 60 | 8 | 2 |
| 10 | 5 | 20 | 75 | 10 | 2 |
| 12 | 6 | 24 | 75 | 12 | 2 |
| 16 | 8 | 32 | 100 | 16 | 2 |
| 20 | 10 | 40 | 100 | 20 | 2 |
| CED | Radius | CEL | OAL | Shank Dia | Teeth |
| 1 | 0.5 | 2 | 50 | 4 | 4 |
| 1.5 | 0.75 | 3 | 50 | 4 | 4 |
| 2 | 1 | 4 | 50 | 4 | 4 |
| 2.5 | 1.25 | 5 | 50 | 4 | 4 |
| 3 | 1.5 | 6 | 50 | 4 | 4 |
| 4 | 2 | 8 | 50 | 4 | 4 |
| 1 | 0.5 | 2 | 50 | 6 | 4 |
| 2 | 1 | 4 | 50 | 6 | 4 |
| 3 | 1.5 | 6 | 50 | 6 | 4 |
| 4 | 2 | 8 | 50 | 6 | 4 |
| 5 | 2.5 | 10 | 50 | 6 | 4 |
| 6 | 3 | 12 | 50 | 6 | 4 |
| 7 | 3.5 | 14 | 60 | 8 | 4 |
| 8 | 4 | 16 | 60 | 8 | 4 |
| 10 | 5 | 20 | 75 | 10 | 4 |
| 12 | 6 | 24 | 75 | 12 | 4 |
| 16 | 8 | 32 | 100 | 16 | 4 |
| 20 | 10 | 40 | 100 | 20 | 4 |
